Overview
The 36W/18W RGB Wall Washer Light (Model 1140) is a linear architectural LED luminaire designed for building facade lighting, exterior wall illumination, and decorative outdoor lighting across India. Equipped with 18 units of 3030 LEDs producing both 3000K warm white and full RGB colour output, it gives lighting designers and building owners the flexibility to use static warm white illumination or dynamic colour-changing effects for facade highlighting and decorative applications. Operating on 220V AC, it connects directly to India’s standard mains supply. The fixture is available in 1 metre and 0.5 metre lengths, and the included remote control allows colour, brightness, and mode adjustment without requiring physical access to the installed fixture.
LED Performance & Light Output
The Model 1140 uses 18 units of 3030 LEDs, providing two distinct output modes: 3000K warm white for architectural accent lighting and full RGB colour mixing for dynamic facade effects. The 30° narrow beam angle concentrates light precisely onto building surfaces, creating defined bands of illumination across exterior walls, columns, arches, and architectural features. This narrow beam characteristic is essential for wall washing applications where light needs to travel across a large vertical surface from a mounting point at floor, cornice, or mid-facade level without excessive light scatter. For building owners, hoteliers, temple trustees, and commercial property managers in India, the dual 3000K and RGB capability in a single fixture eliminates the need for separate static and colour-changing luminaires on the same facade.
IP65 Rating – Dust & Water Protection
The Model 1140 is rated IP65, certifying complete dust ingress protection and resistance to directed water jets from any angle. Outdoor architectural wall washer lights permanently installed on building facades in India are exposed to monsoon rainfall, dust, humidity, bird activity, and UV radiation year-round. IP65 ensures the fixture’s LED array, driver electronics, and wiring connections remain protected from moisture ingress that would otherwise cause premature failure, discolouration, or corrosion in outdoor installation conditions. For hotel exteriors, commercial tower facades, temple structures, housing society entrance gates, and heritage building illumination across coastal Maharashtra, Kerala, Gujarat, and West Bengal, IP65 is a minimum requirement for dependable long-term outdoor fixture performance.
Body Build & Construction
The Model 1140 uses a linear bar-style housing designed for low-profile mounting on building surfaces, ledges, cornices, ground-level uplight channels, and canopy undersides. The slim rectangular profile minimises visual intrusion on the building facade during daylight hours while delivering defined light output at night. Available in both 1 metre and 0.5 metre lengths, the fixture can be used singly or in aligned arrays to cover building facades of varying heights and widths. The aluminium housing supports passive heat dissipation from the 3030 LED chips and driver, maintaining stable output colour temperature and lumen level during continuous overnight operation in the elevated ambient temperatures typical of Indian outdoor environments.
Smart Controls – RGB Remote Operation
The Model 1140 includes a dedicated remote controller, which is a significant operational advantage for facade lighting installations in India where fixtures are mounted at heights or locations that are difficult to access directly after installation. The remote control allows the operator to switch between 3000K warm white and RGB colour modes, adjust brightness levels, select dynamic colour-changing programmes, and set static colour outputs — all from ground level or from within the building. For hospitality properties, event venues, retail showrooms, and housing society entrance areas that require different lighting moods for daily operation, festival periods, or special events, the included remote control provides complete on-demand flexibility without any additional controller investment.
Ideal Applications in India
The 36W RGB wall washer light is suited for a broad range of architectural and decorative outdoor lighting applications across India. Key applications include: hotel and resort facade illumination for hospitality properties in tourism destinations; commercial tower and office building exterior lighting in metro and tier-1 cities; temple and religious structure facade highlighting, particularly in states with large temple heritage such as Tamil Nadu, Odisha, Rajasthan, and Uttar Pradesh; housing society entrance gate and boundary wall lighting; retail showroom and mall exterior lighting; highway-adjacent petrol station and hotel canopy lighting; heritage building illumination projects; and outdoor event venue and farmhouse boundary wall decorative lighting.
Installation & Mounting
The 36W wall washer light (Model 1140) is designed for surface mounting on building facades, ground channels, ledges, canopy undersides, and pole brackets using standard fixing hardware. The 220V AC input connects directly to India’s mains supply through a standard weatherproof outdoor junction box — no step-down transformer or specialised driver enclosure is required. For uplight installations at ground level illuminating building facades from below, the fixture is typically installed in a recessed ground channel or on a low wall bracket with cable routed through conduit to a nearby junction box. The 1 metre and 0.5 metre length options allow flexible layout planning for facades of different dimensions, and multiple units can be aligned and wired in sequence along extended facade runs.
Technical Specifications
| Parameter | Specification |
| Model No. | 1140 |
| Power | 36W / 18W |
| Input Voltage | 220V AC |
| LED Type | 3030 |
| Number of LEDs | 18 Pcs |
| Size | 1 / 0.5 Metre |
| Beam Angle | 30° |
| Colour | 3000K, RGB |
| Remarks | RGB with Remote |
| IP Rating | IP65 |
