24W LED Panel Light – Aluminium Slim Round Recessed | 2400 Lumens | 90-265V | False Ceiling

Overview

The 24W Aluminium Slim Recessed Round LED Panel Light (Model 1311) is the highest-output model in the Aluminium Slim Recessed Round series, designed for large commercial interiors, high-ceiling spaces, and high-intensity lighting requirements in India. With an outer size of 30x30x1.4 cm and a Phi 275 mm cutout, it is the largest format in this product range and delivers 2,400 lumens from 120 SMD LEDs at 24 watts. Operating on a wide input voltage of 90-265V, it maintains stable performance across all Indian electrical supply conditions. It replaces conventional 120W incandescent or 40W CFL fittings, achieving equivalent brightness at a fraction of the operating cost — making it the preferred choice for hotel banquet halls, conference centres, large retail showrooms, and commercial office floors.

LED Performance & Light Output

One hundred and twenty SMD LEDs in an edge-lit arrangement deliver 2,400 lumens of high-intensity, uniformly distributed light across the 30 cm panel surface. The large diffuser panel area produces a wide, even illumination field with no visible LED clusters or brightness gradients — essential in hotel ballrooms, conference halls, and showroom floors where lighting quality is a direct component of the space’s commercial appeal. At 100 lumens per watt, the 24W panel is highly efficient for its output class. The 90-265V wide input voltage ensures consistent, flicker-free performance in locations with variable electrical supply, including large commercial buildings, event venues, and high-occupancy housing society amenity spaces where shared circuit loads cause voltage variation.

Body Build & Construction

The 24W panel’s die-cast aluminium housing manages the thermal output of 120 LEDs and a 24W driver more effectively than any polycarbonate alternative available in the Indian market. Aluminium’s thermal conductivity draws heat away from the LED junction and driver components, maintaining stable operating temperatures that directly determine LED lifespan and maintained lumen output over time. The 30×30 cm outer frame and slim 1.4 cm depth combine to create a bold, architectural ceiling element that suits large false ceiling grid systems in commercial interiors. The white powder-coated finish integrates cleanly into white and off-white ceiling boards, while the recessed profile maintains a flush, professional ceiling surface without visible protrusion.

Voltage Compatibility & Driver Performance

The 90-265V wide input voltage range makes the 24W panel suitable for installation in the full spectrum of Indian commercial and institutional electrical supply conditions — stable urban grid, variable colony supply, industrial estate connections, and rural or farmhouse electrical systems. The integrated constant-current LED driver maintains regulated current delivery to the 120-LED array regardless of supply voltage variation, preventing luminance fluctuation, flicker, or driver damage during voltage transients and load switching. In large commercial installations where multiple high-wattage panels share circuits — banquet halls, office floors, large retail formats — the driver’s load regulation ensures consistent panel performance even during peak-demand periods when supply voltage often sags.

Ideal Applications

The 24W slim round recessed LED panel light is designed for high-intensity lighting in the largest indoor spaces across Indian commercial, institutional, and residential settings. In commercial spaces, it is suited for hotel banquet halls, conference centres, large retail showrooms, restaurant dining areas, and commercial office open-plan floors. For institutional spaces such as hospital waiting halls, school assembly rooms, and government office lobbies, the 2,400-lumen output provides the recommended illumination levels for large occupancy areas. In high-specification residential settings — large villa halls, farmhouse reception rooms, and duplex living spaces — it provides architectural ceiling lighting with a bold 30 cm panel format. Housing society community halls and indoor sports facilities benefit from its high output at a comparatively low 24W consumption.

Energy Efficiency & Cost Savings

The 24W consumption of this panel replaces conventional 120W incandescent lamps and 40W CFL fittings used in large commercial spaces, reducing per-fitting power consumption by up to 80%. In a hotel banquet hall or conference centre with 30 fittings running 8 hours daily, replacing incandescent or halogen fittings with these 24W panels saves tens of thousands of units annually — translating directly into reduced operational electricity costs. The long LED lifespan, combined with the aluminium housing’s thermal management advantages, reduces maintenance call-outs and replacement procurement over the product’s operational life. No UV or IR radiation in the light output makes it safe near fabric displays, exhibition materials, and wooden furniture.

Installation & Mounting

The 24W panel requires a Phi 275 mm round cutout in the false ceiling board — a larger-format standard cutout used in commercial false ceiling grid systems and high-specification residential installations. Spring-clip mounting holds the panel securely in the cutout without screws or additional hardware. The integrated LED driver and flying lead connector simplify wiring to a single mains connection; no external driver box is required. The slim 1.4 cm depth fits within a standard false ceiling cavity, including commercial grid systems with limited plenum depth. Wide voltage input at 90-265V eliminates the need for a voltage stabiliser, even in large commercial buildings where shared circuit load causes supply voltage variation during peak operating hours.

Technical Specifications
